Measuring blood hemoglobin concentration with high accuracy,
ease, and speed
Introduction
The OptoHb101 analyzer measures the hemoglobin concentration by spectroscopic method. High speed, accuracy, and repeatability are the characteristics of this product. In addition, the possibility of storing micro cuvettes in warm places with high humidity (after opening the micro cuvettes can) is one of the advantages of this product. The manufacturing company undertakes to perform periodic calibration and service (for review and needed repairs) during the warranty period and provides the device owner with a health certificate.
Applications
Hospitals and clinics
Blood donation centers
Road and rural medical centers
Universities and research centers
Characteristics
Re-agent free method
Portable and used in non-urban areas
Can be used in hot and humid environments
Appropriate design of micro cuvettes for ease of working with the device when wearing gloves
| 0-20 g/dL | Measurement range |
| less than 30 seconds (for values below 20 g/dL) | Measurement time |
| 10 μL | Sample size |
| 15-40 °C | Operating temperature |
| 0-50 °C | Device storage and transfer temperature |
| 700 to 1100 hPa | Environmental pressure |
| Less than 90 % | Ambient humidity |
| Up to one year under proper storage conditions (micro cuvettes do not lose their effectiveness in high temperature and humidity). | Micro cuvette Storage time |
| 160×95×45 mm | Dimensions |
| 320 g | Weight |
| 3.7 V– rechargeable | Battery |
| 100-240 V /50-60 Hz/ 5 V | Adapter |
| 2 | Degree of pollution |
| II | Overvoltage grouping (overvoltage) |
With only a drop of blood
Capillary, arterial or venous whole blood (EDTA and heparin) can be used
Easy usage
The device has automatic calibration and can be calibrated manually if needed. Easy to set up and simple to use with operating manual
Heat and humidity resistant cuvettes
the possibility of storing micro cuvettes in warm places with high humidity after opening the micro cuvettes can, is one of the advantages of this product
Date and time storage for up to 600 results
